Description
nmistakable ONIX Design
Classic ONIX look modernized for today, Overture fits perfectly alongside Miracle and Mystic. Main body crafted by CNC machines from high-grade aluminium, providing the perfect construction that’s strong and beautiful, especially when paired with the gold-plated volume wheel.
High-End Audio Configuration
Inspired by the audio design of the ONIX Miracle stack, Overture brings the sound of the flagship ESS ES9039PRO DAC to a portable world. Highly detailed, overflowing with dynamics and energy, while bringing husky and smooth voices. Paired with two TPA6120A2 amplifiers for exceptional power from a portable device, offering over 1W @ 32 Ohm.
Pure Music System
Simple and fast system, powered by the Ingenic X2000 platform and designed for the most demanding audiophiles. Avoiding the distractions of modern smartphones and just offering the core music experience. Playing Hi-Res files from MicroSD card, streaming with Tidal or running over DLNA/Airplay, uninterrupted High Fidelity sound is guaranteed.
Multifunctional Hi-Fi Component
While designed mainly as a portable player for headphone users, ONIX XM5 will easily fit into many roles in your home, office or dedicated Hi-Fi rig. Simply streaming Youtube from your phone over Bluetooth, serving as the ultimate USB DAC/Amp with your work laptop, offering digital out for standalone USB DACs or acting as an independent DAC for your powerful monoblock amplifiers, Audiophiles will always find new ways how to utilize the XM5 to its fullest potential.
Specification
Dimensions: 115 x 70 x 19 mm
Weight: 275g
System Platform: Ingenic X2000
System: In-House Developed
Display: Square 3-inch OLED Touch Screen 720p
Playback: MicroSD Card (up to 2TB), Tidal Online Streaming
Controls: Touch Screen, 4 Hardware Buttons, Volume Wheel
Remote Controls: SyncLink through Eddict Player app (Android & iOS)
Bluetooth Connectivity: Two-Way Bluetooth 5.2
Bluetooth Codec Support: LDAC / aptX HD / aptX / SBC / AAC
Wi-Fi Connectivity: 2.4G/5G, DLNA, AirPlay, Tidal
USB DAC: Dedicated XMOS XU316 Chip
Hi-Res File Support: PCM 768kHz / 32bit, DSD512
Headphone Outputs: 3.5mm Single-Ended, 4.4mm Balanced
Battery: 7000 mAh, standard USB-C charging port
Battery life: Up to 14 hours SE, 12 hours BAL
3.5mm Single-Ended Output
Output Power Low gain:
0.79V@32Ω (19mW@32Ω) (THD+N<0.002%)
Output Power High gain:
3.15@32Ω (310mW@32Ω) (THD+N<1%)
3.65V@300Ω (40mW@300Ω) (THD+N<0.02%)
Output Impedance: 4.7Ω
4.4mm Balanced Output
Output Power Low gain:
1.5V@32Ω (75mW@32Ω) (THD+N<0.0008%)
Output Power High gain:
5.7V@32Ω (1069mW@32Ω) (THD+N<1%)
6.9V@300Ω (158mW@300Ω) (THD+N<1%)
Frequency Response: 20Hz-40kHz (-0.5dB)
THD+N: 0.0006% @32Ω (A-Weight)
Dynamic Range: 121dB @32Ω (A-Weight)
Channel Separation: 100dB
Signal-to-Noise Ratio : 121dB @32Ω (A-Weight)
Noise: 109dB @32Ω (A-Weight)
Output Impedance: 6.6Ω
